Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage

Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage

  • Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage
  • Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage
  • Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage
  • Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage
Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage
Product Details:
Place of Origin: China
Brand Name: Oasis brand
Certification: GB/T 19001-2006/ISO9001:2015
Model Number: High Temp/ Low Temp
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiate
Packaging Details: carton
Delivery Time: 5-6 weeks
Payment Terms: T/T
Supply Ability: 100 set per week
Contact Now
Detailed Product Description
Material: Stainless Steel,colorbond,aluminum,checker Plate Steel Thickness: 0.4mm,0.6mm,0.8mm,1.0mm, 1.2mm,1.5mm,2.0mm Etc
Panel Thickness: 50mm,75mm,100mm,150mm,200mm Corner Type: Right Angle Or Rounded Corner
Floor Type: Walk-in Or Recessed Dimension: Customized
Function: Insulation And Refrigeration After-sales Service: Online Support
Temperature: Suitable For High, Medium And Low Temp. Power: 110V/220V/380V
Density: 42KG/M3 Condition: Oasis Brand New
High Light:

ISO9001 Recessed Walk In Chiller Rooms

,

SS304 Cool Room Food Storage

,

SS304 Walk In Chiller Rooms

Walk In Coolroom,Stainless Steel Commercial Cold Room,White Colorbond Cold Room Cooler For Food Storage,Kitchen Frozen



Oasis Refrigeration Equipment Co.,Ltd is a high technology comprehensive enterprises, which engaged in design, research, production, marketing and installation.



Features:



1. Oasis Cold room suitable for temperature -45℃ to over 5 ℃.

2. Combination panels with camlocks and tongue-and-groove mounted, very easy to intall according to installtion drawing.

3. Insulation panel density 42KG.

4. Hidden floor and ceiling if needed

5. Coolroom corners can be rounded corner radius 10mm in accordance with hygienic-sanitary regulations.

6. All kinds of doors have fabricated heaters inside to avoid door frozen when working.

7. Around doors fabricated rubbles to ensure sealing property.

8. Light weight, high strength, meeting the demand of outside loading.

9. No mildow, worm resisting.

10 Option fittings: view window, kick plate, alarm, air curtains, PVC curtains, LED light, controllers.

11. Matched refrigeration systems if needed.



Description



1. Materials - We have many materials of coldroom for your referance. Generally, stainless steel coldroom often used for 5 star hotel. Salt steel is special type for coastal area, having anti-corruption design, and cheaper than stainless steel when the budget is limited. Colorbond materials is common type, widely used and competitive.



Detail Standard Face plate According to GB/T23932-2009 double skin metal faced insulating panels for builing
According to JB/T6527-2006 The sandwich panels use for prefab cold room
Metal steel face plate (exterior +interior) Metal steel plate thickness PU Thickness (mm)
50 75 100 120 150 200
Colorbond steel + Colorbond steel 0.4-0.8
Salinized steel + Salinized steel 0.4-1.0
Stainless steel +Stainless steel 0.5-2.0
Aluminum steel + Aluminum steel 0.4-2.0
Colorbond steel + Stainless steel Customized
Colorbond steel + Salinized steel Customized
Colorbond steel + Galvanized steel Customized
Colorbond steel + Aluminum steel Customized
Bare PU panel
Customized Customized





2. Structure - Combination cold rooms are combined piece by piece according to intallation drawing.It's very easy to install by yourself. Our panel made by high pressure foaming, standard width is 1160mm, height can be from 2000mm to 8000mm, moreover, all these panels can be customized as your specical request. We use high quality, top grade and perfect appearance to show the unique features of Coldroom, with the high density metal panel and camlock, can use under 150 kg tension.





Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage 0



3. Cool room panel thickness - Panel thickness and working temperature,based on ambient temperature 35℃. Different thickness panel, the temperature using range is different.



Panel Thickness MM 50 75 100 125 150 200
Heat Conductivity W(M.K) 0.27 0.24 0.18 0.17 0.16 0.14
Working Temperature ≥5℃ ≥-5℃ ≥-25℃ ≥-30℃ ≥-35℃ ≥-45℃
Limiting Temperature ≥-5℃ ≥-10℃ ≥-30℃ ≥-35℃ ≥-40℃ ≥-50℃





4. Corner type - Of course, right angle corner is common that we can supply . If needed, we have curved corner design. This type is environmental protection, beautiful and easy to clean.



5. Floor type - The coldroom floor have two type according to request. The Walk-in type floor is installed on the ground directly, the panel interior steel request thicker than wall and ceiling, like 1.2mm thickness stainless steel checker. The recessed type, generally will recess 200mm (or 150mm...) under the ground, then backfill concrete and tile on the bare PU panels, to enhance the hardness of the floor and allow forklift drive inside.





6. Doors - Gennerally, we will offer swing (hinged) or sliding door for coldrrom as your request. If you have special request, we can customize accordingly.





7. Application - We can supply high temperature (chiller) coldroom, low temperature (Freezer) coldroom and blast freezer as your request. Such as Beverage Chiller, Meat Chiller, Seafood Chiller, Vegetable Chiller,Fruit Chiller,Wast Chiller, Meat Freezer, Seafood Freezer,General Freezer,Kitchen Freezer,Kit Freezer.





8. Refrigeration system - We can also supply refrigeration system to match different temperature coldroom. We have , Tecumseh,Copeland, Maneurop,Performer,Highly brand air-cooled / water-cooled system for your referance. Also, have our own brand Coldmach full set intelligent condensing unit, Monoblock unit etc.

Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage 1



9. Cooperative partners -The coldroom, freezer and chiller room and blast freezer room can be used for hotel,gastronomy, food production, staff restaurant, hospitals, cold chain logistics, ship ect. We cooperated with many company, like Marriott,Hyatt,Hilton,Renaissance Marriott,Courtyard,Crowne Plaza, Internaltion Hotels Group, Sofitel,Sheraton,,Wanda Group etc.

Customized Recessed 200mm Walk In Chiller Rooms SS304 Cool Room Food Storage 2







10. Certificate - Our high quality coldroom panels have passed quality inspection.We got ISO9001 Quality Certification, QS Industrial production license CE Certificate (Coldroom panel & door), Inspection Report,B1 (GB/T 8624) Fire inspection report,SGS test report. Here are certificates for your referance.





Our strengths:



1. Focus on refrigeration system solution more than 18 years.

2. Strong R&D department ensure reasonable design and excellent quality.

3. We have experienced engineers and technician team to help you install, and after-sale service.

4. 24 hours online service.

5. High efficiency team work full of love & reponsibility.



Should you have any question, feel free to contact. You are all welcome at any time.
