Customized Bakery Walk In Freezer Room Prefabricated Walk In Coldroom

Prefabricated Walk In Bakery Freezer Room



Oasis Chiller and freezer roooms customized,  made of different materials, can be used for food storage, cooling and processing.



We can design according to your request.



*  Pre-fabricated wall floor and ceiling insulation panels.



Insulation panels spec:





Description



1. Materials - Coldroom panels materials can be stainless steel,colorbond,aluminum,galvanized,salt steel etc.



Detail Standard Face plate	According to GB/T23932-2009 double skin metal faced insulating panels for builing
	According to JB/T6527-2006 The sandwich panels use for prefab cold room
Metal steel face plate (exterior +interior)	Metal steel plate thickness	PU Thickness (mm)
		50	75	100	120	150	200
Colorbond steel + Colorbond steel	0.4-0.8	√	√	√	√	√	√
Salinized steel + Salinized steel	0.4-1.0	√	√	√	√	√	√
Stainless steel +Stainless steel	0.5-2.0	√	√	√	√	√	√
Aluminum steel + Aluminum steel	0.4-2.0	√	√	√	√	√	√
Colorbond steel + Stainless steel	Customized	√	√	√	√	√	√
Colorbond steel + Salinized steel	Customized	√	√	√	√	√	√
Colorbond steel + Galvanized steel	Customized	√	√	√	√	√	√
Colorbond steel + Aluminum steel	Customized	√	√	√	√	√	√
Bare PU panel		√	√	√	√	√	√
Customized	Customized	√	√	√	√	√	√





2. Coldroom structure:  Walk in Cold room set combined piece by piece according to drawings. Each panel fabricated with camlock, with tongue-and - groove joint, easy to install by clients themself.







3. Panel Thickness :  Panel thickness and working temperature based on ambient temperature 35℃

You can choose thickness according to temperature rrequest.



Panel Thickness	MM	50	75	100	125	150	200
Heat Conductivity	W(M.K)	0.27	0.24	0.18	0.17	0.16	0.14
Working Temperature	℃	≥5℃	≥-5℃	≥-25℃	≥-30℃	≥-35℃	≥-45℃
Limiting Temperature	℃	≥-5℃	≥-10℃	≥-30℃	≥-35℃	≥-40℃	≥-50℃





4. Corner type:  Generally, right angle corner is common used for coldroom panels. But  we can also design curved corner if needed.It is environmental protection, beautiful and easy to clean.



5. Floor type,  This deep freezer cold room is walk in type floor. Moreover, we have recessed type for your choice. Recessed type can backfill concrete on floor panel, to enhance hardness to allow forklift drive inside.



6.  Door type:  This deep freezer cold room showed above have sliding door and hinged door for your referance. One door for one room or two doors as your choice.



7.  Application:  We can supply high temperature (chiller) coldroom, low temperature (Freezer) coldroom and blast freezer as your request.



Such as Beverage Chiller, Meat Chiller, Seafood Chiller, Vegetable Chiller,Fruit Chiller,Wast Chiller, Meat Freezer, Seafood Freezer,General Freezer,Kitchen Freezer,Kit Freezer. You can take below as referance.



Storage products	Storage temperature approach
Vegetables, Fruit storage, Dry food	-5~5degree centigrade
Drink, Beer storage, Beverage	2~8 degree centigrade
Meat, Fish, Seafood freeze storage	-18~--25 degree centigrade
Medicine storage	2~8 degree centigrade
Medicine freeze storage	-25 degree centigrade
Meat, Fish blast freezer	-35~-40 degree centigrade





8. Refrigeration systems :



We supply all kinds of refrigeration system to match different temperature coldroom.



brand air-cooled / water-cooled system,

Emerson Copeland air-cooled / water-cooled system,

Tecumseh air-cooled / water-cooled system.

Our own brand Coldmach full set intelligent refrigeration system.

And we can customize refrigeration system





9. Cooperative partner:



The walk in cold rooms, freezer and chiller rooms and blast freezer rooms can be used for hotel,gastronomy, food production, staff restaurant, hospitals, cold chain logistics, ship ect. We cooperated with many company, like Marriott,Hyatt,Hilton,Renaissance Marriott,Courtyard,Crowne Plaza, Internaltion Hotels Group, Sofitel,Sheraton,,Wanda Group etc.











10. We can supply certificate documents as follows:



- QS Industrial production license

- CE Certificate (Coldroom panel & door)

- B1 (GB/T 8624) Fire inspection report

- B2 (GB/T 8624) Fire inspection report

- SGS test report (single material)

- SGS test report (composite material)



11. Coldroom inquiry:



Let us know coldroom dimension, storage what kind of food, temperature, door type, panel materials, and refrigeration system type. Then we can make a firm offer ASAP.



Cold room size (L x W x H)	Food &Temperature	Door type	Cold room material	Refrigeration system type
2x2x2.6m	Fruit, +2C degree	Hinged door	0.6mm stainless steel	Air-cooled
4x3x2.7m	Frozen meat, -24C degree	Sliding door	0.6mm colorbond	Air-cooled
5x3x2.7m	Seafood, -24C degree	Sliding door	0.8mm aluminum	Water-cooled
5x6x2.8m	beverage, +2C degree	Hinged door	0.7mm galvanized sheet	Air-cooled









Should you have any question, feel free to contact.You are all welcome at any time
